支持主板定制设计服务。
Meegopad-Comput Stick/MEEGOPAD T08
Contact: Elaine  Email:elaine@meegopad.cn     Mobile:0086-15889685436     skype: lichen0000lichen1
Specification www.meegopad.cn
General
Style Ultra-mini PC——Compute Stick
OS Windows 10
CPU/GPU
CPU/GPU Intel Atom Cherry Trail x5-Z8350 CPU (14NM) 2MB L2 Cache
CPU Frequency 1.44GHZ
Turbo Frequency 1.84GHZ
Core Quad Core
GPU Intel HD Graphic,12EU Gen8LP 600MHz
Storage
Ram DDR3L 2/4GB 1333/1600
Storage eMMC5.0 /5.1 32GB/64GB.
Expand Storage Micro SDTFcard, max 64G. Support external USB-Device
Network Communication
WiFi RTL8821 ac/a/b/g/n Wireless(dual band WIFI2.4G/5G
Bluetooth BT4.2
I/O Ports
HDMI 1920*1200 HDMI port
Data 2*USB2.0, 1*Micro USB2.0
USB type C 1*USB3.1 type c,with USB+dp+power
Power 1*MicroUSB2.0
Expand Storage Micro SD*1
Audio Headphone out/Mic-in for  iPhone format
Feature Key Power On/Off
Special Function
FAN 3004FAN (with fan)
Power Adapter
Power Adapter Input 100V-240V 50/60Hz Output 5V 3A
