C6C
If you want to know more about our product,please sent email to us.
| General | |
  |
|
| Style | 12*12cm MAINBOARD / CORE SERIES |
| OS | Windows7/Windows8/Windows10 |
| CPU/GPU | |
| Chip | Intel Chip |
| CPU | J1900/I5 4200U |
| Graphics Card | Intel Core Graphics Card |
| Audio | ALC962 |
| Storage | |
| Hard Disk | MSATA3.0 *1 ; SATA *1 |
| Memory | DDR3 Maximun Support 8GB |
| Network Communication | |
| WiFi | 300Mbps Wireless LAN; Wifi Port *1; |
| Wired LAN | RTL8111 1000M/ Intel AC3160 optional |
| I/O Ports | |
| HDMI | 1*HDMI Port |
| Data | 2*USB2.0/ 4*USB3.0 |
| LAN | 2*LAN Port |
| VGA | 1*VGA Port |
| Audio | 1*AUDIO; 1*MIC |
| Option | 2*COM Port |
| Feature Key | PC Power On/Off，Power Indicator |
| Power | |
| Power | 12V-5A |
| Fan | |
| Fan | Intelligent Small Fan |
| Physical Characteristics | |
| Dimension | 13.5*13*4cm |
| Weight | 1.5KG |
| Case | All Aluminium Frame; All Aluminium Case for Cooling |
| Color | Silver White/Black/Customized |
| PACKAGE include（MAINBOARD+CPU+MEMORY+HARD DISK+WIFI+POWER ADAPTER+PACKING） | |
