J9B
If you want to know more about our product,please sent email to us.
| General | |
| Style | Industrial Mini PC |
| OS | Windows7/8/10 |
| CPU/GPU | |
| CPU/GPU | Intel® Baytrail Celeron® Processor J Series Cache 2 MB L2. N2830/J1800/J1900 |
| CPU Frequency | 2.00 GHz |
| Turbo Frequency | 2.42GHz |
| Core | Quad Core |
| GPU | |
| Storage | |
| Ram | DDR3L 2G/4G/8G 1066/1333/1600 |
| Storage | MSATA SSD & SATA HDD |
| Expand Storage | |
| Network Communication | |
| WiFi | Optional |
| Lan | Intel WGI211AT *4,Support network wake |
| Bluetooth | BT optional |
| I/O Ports | |
| RJ45 | WGI211AT (Intel WG82583 optional)Gigabit 2.0GHZ*4 |
| COM | RJ45 COM Port (Optional) |
| HDMI | HDMI*1 |
| VGA | VGA*1 |
| Audio Chipset | Realtek ALC662 |
| USB | 2 standard USB2.0 |
| DC Jack | DC Jack*1 |
| Feature Key | Power On/Off |
| Pin I/O Slot | |
| Built In Pin Header | LPC-CLK*1, JPWR-SATA*1, JDC-PWR*1, 1个CLR-CMOS*1, Sim Card Slot*1 |
| Power Adapter | |
| Power Adapter | Input 100V-240V 50/60Hz Output 12V 3A |
| Physical Characteristics | |
| Working Tempeturate | (-10)℃~60℃ (SSD/mSata), 0-50℃ (HDD) |
| Sotrage Tempeturate | (-40)℃~85℃ |
| Relative Hnmidity | 0%~95%@40℃ Non-Condensing |
| Remark: Metal Housing, Suitable size for cooling | |
